Autel Robotics Autel Alpha L35T Bundle

by Autel
$19,289.00
  • Autel Alpha is an intelligent industrial drone for multi-purpose, boasting significant enhancements in autonomous right capabilities, anti-interference
    capabilities, obstacle avoidance capabilities, transmission technology, and battery systems. With a foldable design and IP55-rating level, it tackles challenging environments. The built-in RTK dual-antenna system ensures precise control within millimeters when conducting the missions. The DG-L35T gimbal integrates a 560x super hybrid zoom camera, dual thermal imaging cameras, ultra-sensitive starlight night vision camera, and a laser range finder, providing more professional and comprehensive solutions for public safety, energy inspections, and emergency management.

    MFG Part Number: EVO-ALPHA-L35T-BUN

    Model Number: Autel Alpha L35T Bundle



    1. IP 55 Rating
    2. Hot Swappable Batteries
    3. AI Recognition and Counting of People, Vehicles and Boats
    4. Target Tracking
    5. 35x Optical Zoom and 560x Hybrid Zoom
    6. 640x512 Thermal Resolution
    7. 56x hybrid thermal zoom
    8. 13mm Focal Length Wide Angle Range Thermal
    9. 45mm Focal Length Long Range Thermal
    10. 720 Degree Omnidirectional Detection
    11. Enhanced Anti-Interference and Anti-Jamming Capabilities
    12. Advanced Level of Autonomy

  • Aircraft

    Weight (Battery and gimbal included)

    6100g

    Max. Payload

    3000g

    Dimensions

    1185*942*262mm (unfolded, incl. propellers)
    788*551*255mm (unfolded, excl. propellers)
    453*262*245mm (folded, excl. propellers)

    Diagonal Wheelbase

    810mm

    Max Flight Time (windless)

    40mins

    Max Hovering Time (windless)

    38mins

    Max Horizontal Speed (windless near sea level)

    24m/s

    Max Wind Resistance

    15m/s

    Hovering Accuracy

    Vertically:
    ±0.1 m (when vision systems working normally);
    ±0.3 m (when GNSS working normally);
    Horizontally:
    ±0.15 m (when vision systems working normally);
    ±0.3 m (when GNSS working normally)

    IP Rating

    IP55

    Operating Temperature

    -20℃ to +50℃

    GNSS

    GPS+GLONASS+BeiDou+Galileo

    DG-L35T

    Autel Alpha Wide Camera

    Sensor

    1/2 CMOS, Effective pixels: 48M

    Lens

    DFOV: 84°
    Equivalent Focal Length: 24 mm
    Aperture: f/2.8
    Focusing Distance: 1m ~ ∞

    ISO Range

    Photo: ISO100~ISO6400
    Video: ISO100~ISO64000 (Night scene mode: up to ISO256000)

    Autel Alpha Zoom Camera

    Sensor

    1/1.8" CMOS

    Lens

    FOV: 66.7-34.6°
    Focal Length: 34.7~838mm
    Aperture: f/1.61~f/5.19

    Zoom Range

    Optical Zoom: 1~35 times
    Digital Zoom: 35~560 times

    ISO Range

    Photo: ISO100~ISO6400
    Video: ISO100~ISO64000 (Night scene mode: up to ISO320000)


    Format: 8bit JPG,12bit DNG
    Resolution: 3840*2160

    Video

    Format: MP4/MOV
    Max Resolution: 3840*2160 P30

    Autel Alpha Thermal Camera (Wide)

    Sensor

    Uncooled VOx Microbolometer

    Lens

    FOV:42°
    Focal length: 13mm
    Aperture: f/1.2

    Resolution

    640*512 P25

    Temperature Measurement Range

    -20℃ to +150℃,0℃ to +550℃

    Temperature Measurement Accuracy

    3℃ or ±3% of reading (using the larger value)
    @ ambient temperature range from -4℉ to 140℉ (-20℃ to 60℃)

    Autel Alpha Thermal Camera (Tele)

    Sensor

    Uncooled VOx Microbolometer

    Lens

    FOV:12.3°
    Focal length: 45mm
    Aperture: f/1.2

    Zoom Range

    Wide Digital Zoom: 1~3.5 times
    Tele Digital Zoom: 3.5~56 times

    Resolution

    640*512 P25

    Temperature Measurement Range

    -20℃ to +150℃,0℃ to +550℃

    Temperature Measurement Accuracy

    3℃ or ±3% of reading (using the larger value) @ ambient temperature range from -4℉ to 140℉ (-20℃ to 60℃)

    Autel Alpha Laser Rangefinder

    Measuring Range

    10-2000m

    Measurement Accuracy

    ± (1m + D×0.15%)
    *D is the distance to a vertical surface

  • 1 Year Limited
